Arduino Nano

Arduino

Key Features

  • MICROCONTROLLER: ATmega328
  • ARCHITECTURE: AVR
  • OPERATING VOLTAGE: 5 V
  • FLASH MEMORY: 32 KB of which 2 KB used by bootloader
  • SRAM: 2 KB
  • CLOCK SPEED: 16 MHz
  • ANALOG IN PINS: 8
  • EEPROM: 1 KB
  • DC CURRENT PER I/O PINS: 40 mA (I/O Pins)
  • INPUT VOLTAGE: 7-12 V
  • DIGITAL I/O PINS: 22 (6 of which are PWM)
  • PWM OUTPUT: 6
  • POWER CONSUMPTION: 19 mA
  • PCB SIZE: 18 x 45 mm
  • WEIGHT: 7 g
  • Click Here to Download Open Source Arduino Software

 1,000.00  1,300.00

Compare

Arduino Nano

Buy a complete range of Arduino boards and their component at a very cheap price from all over Pakistan. We are the one and only store in Pakistan providing our customers with a wide range of electronic products and components at a very reasonable price at their doorstep. You can buy Arduino Nano anywhere from Pakistan or by visiting Electronic Power House (EPH) and Tetralink Technologies (TLT) in Lahore.

Overview

The Arduino Nano is a small, complete, and breadboard-friendly board based on the ATmega328 (Arduino Nano 3.x). It has more or less the same functionality of the Arduino Duemilanove, but in a different package. It lacks only a DC power jack, and works with a Mini-B USB cable instead of a standard one.

Getting Started

Find inspiration for your projects with the Nano board from our tutorial platformProject Hub.

You can find in theGetting Started with Arduino Nanosection all the information you need to configure your board, use theArduino Software (IDE), and start tinkering with coding and electronics.

From theTutorialssection you can find examples from libraries and built-in sketches as well other useful information to expand your knowledge of the Arduino hardware and software.

brands

Arduino

Tech specs

  • MICROCONTROLLER ATmega328
    ARCHITECTURE AVR
    OPERATING VOLTAGE 5 V
    FLASH MEMORY 32 KB of which 2 KB used by bootloader
    SRAM 2 KB
    CLOCK SPEED 16 MHz
    ANALOG IN PINS 8
    EEPROM 1 KB
    DC CURRENT PER I/O PINS 40 mA (I/O Pins)
    INPUT VOLTAGE 7-12 V
    DIGITAL I/O PINS 22 (6 of which are PWM)
    PWM OUTPUT 6
    POWER CONSUMPTION 19 mA
    PCB SIZE 18 x 45 mm
    WEIGHT 7 g
