arm core microcontroller
Showing 1–28 of 90 results
-
Arduino, Arduino Boards & Components, Development Kits
0-60V Battery Level Meter
It is the perfect multifunctional tool for troubleshooting. Measure the power and energy consumption of any battery-powered device. The easy-to-read LCD screen provides clear digital readings. When connected, the wattmeter will continuously provide real-time readings of amperes, volts and watts. The device can calculate the voltage, current, power, discharge capacity and discharge time of the aircraft, and calculate the force effect of the multi-axis aircraft. Large screen reality, backlight can be set, function switching query.
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
140 jumper wire box
?Key Features :
- High-quality materials: These jumpers are made of excellent copper-coated material with outstanding conductivity and transmission performance, easily reshaped for connection testing.
- Easy to use: Each breadboard jumper has stripped ends for easy insertion into the breadboard, connecting via pin connections without soldering.
- Easy to store: All jumper wires are neatly stored in the included plastic sorting box, which helps you keep the jumpers organized for easy identification and use.
- Broad application range: These flexible wire bridges for breadboards and lab boards are ideal for use with plugboards, prototypes, LED strips, test circuits, and more. They are widely used in electronic projects for connections and rapid circuit testing.
- Wide variety: The set includes a diverse range of wire bridges in the most common lengths, allowing you to complete any project successfully.
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
37-1 sensor kit
?Key Features :
- KY-001 Temperature sensor module
- KY-002 Vibration switch module
- KY-003 Hall magnetic sensor module
- KY-004 Key switch module
- KY-005 Infrared emission sensor module
- KY-006 Small passive buzzer module
- KY-008 Laser sensor module
- KY-009 3-color full-color LED SMD modules
- KY-010 Optical broken module
- KY-011 2-color LED module
- KY-012 Active buzzer module
- KY-013 Temperature sensor module
- KY-015 Temperature and humidity sensor module
- KY-016 3-color LED module
- KY-017 Mercury open optical module
- KY-018 Photo resistor module
- KY-019 5V relay module
- KY-020 Tilt switch module
- KY-021 Mini magnetic reed modules
- KY-022 Infrared sensor receiver module
- KY-023 XY-axis joystick module
- KY-024 Linear magnetic Hall sensors
- KY-025 Reed module
- KY-026 Flame sensor module
- KY-027 Magic light cup module
- KY-028 Temperature sensor module
- KY-029 Yin Yi 2-color LED module 3MM
- KY-031 Knock Sensor module
- KY-032 Obstacle avoidance sensor module
- KY-033 Hunt sensor module
- KY-034 Automatic flashing colorful LED module
- KY-035 Class Bihor magnetic sensor
- KY-036 Metal touch sensor module
- KY-037 Sensitive microphone sensor module
- KY-038 Microphone sound sensor module
- KY-039 Detect the heartbeat module
- KY-040 Rotary encoder module
SKU: n/a -
-
Arduino, Arduino Boards & Components, Development Kits
4×4 Keypad Matrix Keypad
?Key Features :
-
- Ultra-thin design & adhesive backing provides easy integration to any project
- Excellent price-performance ratio
- Easy communication with any microcontroller
- 5 pins 2.54mm pitch connector,?4x 4type 16 keys.
- Sticker can peel off for adhesive mounting.
- Used widely in industrial and home electronic equipments, instrument, etc.
- This allows a microcontroller to ?scan? the 8 output pins to see which of the 16 buttons is being pressed.
SKU: n/a -
-
Arduino, Arduino Boards & Components, Development Kits
5v 1a Power Bank Charger Step Up Boost Charging Circuit Module Lithium Battery Diy Power Bank Module
-6%Arduino, Arduino Boards & Components, Development Kits5v 1a Power Bank Charger Step Up Boost Charging Circuit Module Lithium Battery Diy Power Bank Module
?Key Features :
- Input: 5 V 1A
- Charging and discharging indication
- Size: approximately 22mm * width 17mm * thickness 11mm
- Internally installed charging and discharging power MOS
- Preset 4.2V charging voltage, precision ?1%
- Max 8uA standby current
- Integration charging management and discharging management
- Intelligent temperature control and overtemperature protection
- Integration output overvoltage protection, short circuit protection, overload protection
- Integration overcharging and over-discharging protection
- Support trickle mode and zero voltage charging
- Output:?5 V 1A
- Lithium voltage: 3 v-4.3 V
- Ports: Micro USB Android port.?USB port output
- When charging: red light flashing Full charged: red light for a long time
- Has protection functions, protects from overcharger/overload (supports charger and discharger at the same time)
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
A4988 A4988 Stepper Motor Driver
?Key Features :
-
- Supply Voltage : 8-35 VDC.
- Current : 1.0A (no heatsink ).
- Current : 2.0A (with heat-sinking).
- logic input : 3 ? 5.5V .
- Automatic current decay mode detection/choice.
- Mixed with slow current decay mode.
- The low power dissipation of synchronous rectifier.
- Internal UVLO(ultra voltage lockout).
- Crossover current protection.
- Thermal shutdown circuit.
- Ground fault protection.
- Loading and short circuit protection.
- The optional five-step mode: full, 1/2, 1/4, 1/8 and 1/16.
SKU: n/a -
-
Arduino, Arduino Boards & Components, Development Kits
Active Low Level Trigger Buzzer Alarm Module
-6%Arduino, Arduino Boards & Components, Development KitsActive Low Level Trigger Buzzer Alarm Module
?Key Features :
- Product Name:3.3 to 5V Active Buzzer Alarm Module Sensor And 3 Pin TTL Cable
- The Transistor drive module uses 8550
- With fixed bolt hole- easy installation- 2.6mm aperture.
- Operating voltage 3.3V-5V
- PCB dimensions: 34.28 mm (L) * 13.29 mm (W) * 11.5 mm (H)
- Wire length: 20.5cm
- Weight: 7 gm.
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
Active Piezo Buzzer 3v To 12V Active Buzzer for Arduino
-7%Arduino, Arduino Boards & Components, Development KitsActive Piezo Buzzer 3v To 12V Active Buzzer for Arduino
?Key Features :
- Piezo sounders contain a piezoelectric vibration plate (also known as a piezo element) within a molded case.
- Sound is emitted when a voltage is applied and the piezo element inside the case vibrates.
- Piezo buzzers generally use less current.
- Have a higher sound output and a wider operating voltage.
- Buzzers and Sounders can also be split into Audio Indicators and Audio Transducers.
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
ADXL-1345 Tripple Axis Accelerometer Module
-3%Arduino, Arduino Boards & Components, Development KitsADXL-1345 Tripple Axis Accelerometer Module
?Key Features :
-
- Voltage ? Supply : 3.3 V/ 5V.
- Interface 😕I?C, SPI.
- Sensing Range 😕?2g, 4g, 8g, 16g.
- Sensitivity:
- X : 28.6 LSB/g.
- Y : 31.2 LSB/g.
- Z : 34.5 LSB/g.
- Sensor Type 😕Accelerometer 3 Axis.
- Dimensions : 28 mm x 14 mm.
- Weight : 10 gm.
- Ultra Low Power: 40?A in measurement mode, 0.1?A in standby@ 2.5V.
- Free-Fall Detection.
- Tap/Double Tap Detection.
- Flexible interrupt modes mappable to either interrupt pin Measurement ranges selectable via serial command Bandwidth selectable via serial command
- Wide temperature range (?40?C to +85?C).
- 10,000 g shock survival.
- Support 5V/3.3V voltage input, on-board RT9161 power chip, lower pressure drop faster than the 1117, faster load speed of response, very suitable for high-noise power supply environment.
- User-selectable resolution
- Fixed 10-bit resolution.
- Full resolution, where resolution increases with?g?range, up to 13-bit resolution at ?16?g?(maintaining 4 mg/LSB scale factor in all?g?ranges).
SKU: n/a -
-
Arduino, Arduino Boards & Components, Development Kits
Arduino 28byj48 5v Stepper Motor With Uln2003 Driver
-3%Arduino, Arduino Boards & Components, Development KitsArduino 28byj48 5v Stepper Motor With Uln2003 Driver
?Key Features :
- Model : 28BYJ-48
- Number of Phase : 4
- Speed Variation Ratio : 1/64
- Stride Angle : 5.625? /64
- Rated voltage : DC [5v – 12v]
- DC resistance : 5v: 60??7%(25?); 12v: 130??7%(25?)
- Frequency : 100Hz
- Idle In-traction Frequency : > 600Hz
- Idle Out-traction Frequency : > 1000Hz
- In-traction Torque >34.3mN.m(120Hz)
- Self-positioning Torque : 5v: >29.3mN.m; 12v: >42.1mN.m
- Friction torque : 600-1200 gf.cm
- Pull in torque : 300 gf.cm
- Insulated resistance >10M?(500V)
- Insulated electricity power : 600VAC/1mA/1s
- Insulation grade : A
- Rise in Temperature <40K(120Hz)
- Noise <35dB(120Hz,No load,10cm)
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
Arduino Due
Key Features
- Microcontroller : Atmel SAM3X8E ARM Cortex-M3
- CPU: 32-Bit
- Digital I/O: Pins54
- PWM Output: 12
- PWM Output: 12
- Analog Input: 12
- Analog Input: 12
- Flash Memory (Program Memory): 512 KB
- SRAM96KB (two banks: 64KB and 32KB)
- Operating Voltage: 3.3V
- Input Voltage: 7-12 V
- Oscillator up to 84 MHz
- Arduino Due is open-source hardware! You can build your own board using the following files
- Click Here to Download Open Source Arduino Software
- EAGLE FILES IN .ZIP
- SCHEMATICS
- FRITZING IN .FZPZ
- BOARD SIZE .IN
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
Arduino MEGA 2560 PRO Mini
Key Features
- Item type:MEGA 2560 Pro Embedded USB CH340G ATMEGA2560-16AU Chip
- Form factor-Mega PRO
- Microcontroller-ATmega 2560 (16 MHz)
- USB-UART-CH340G interface (12 MHz)
- input voltage-6-9 V (peack 18 V)
- PC-MicroUSB connection socket
- 70 digital I / O
- 16 analog entries
- 14 PWM
- 4 UART bus
- Click Here to Download Open Source Arduino Software
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
Arduino MEGA2560
Key Features
- PERATING VOLTAGE: 5V
- INPUT VOLTAGE (RECOMMENDED): 7-12V
- INPUT VOLTAGE (LIMIT): 6-20V
- DIGITAL I/O PINS: 54 (of which 15 provide PWM output)
- ANALOG INPUT PINS: 16DC
- CURRENT PER I/O PIN20 mADC CURRENT FOR 3.3V PIN: 50 mA
- FLASH MEMORY: 256 KB of which 8 KB used by bootloader
- SRAM: 8KB
- EEPROM: 4 KB
- CLOCK SPEED16 MHz
- LED_BUILTIN13
- LENGTH: 101.52 mm
- WIDTH: 53.3 mm
- WEIGHT: 37 g
- Click Here to Download Open Source Arduino Software
- EAGLE FILES IN .ZIP
- SCHEMATICS
- BOARD SIZE .IN
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
Arduino Nano MEGA328P-without Wire
Key Features:
- The Nano is using the chips ATmega+328P and CH340, not FT232 as official Arduino, so pls. use the driver from our site.
- It is a smallest, complete, and breadboard friendly board. It has everything that Diecimila/Duemilanove has (electrically) with more analog input pins and onboard +5V AREF jumper.
- Nano’s got the breadboard-ability of the Boarduino and the Mini+USB with smaller footprint than either, so users have more breadboard space. It’s got a pin layout that works well with the Mini or the Basic Stamp (TX, RX, ATN, GND on one top, power and ground on the other).
- The Nano can be powered via the Mini-B USB connection, 7-12V unregulated external power supply (pin 30), or 5V regulated external power supply (pin 27). The power source is automatically selected to the highest voltage source.
- Learn Arduino Nano with ease: Our ELEGOO Nano Board is the perfect choice for beginners and experts alike, with tutorials available to help you get started.
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
Blue 1602 LCD 16×2 for Soler Inverter
Key Features :
-
-
- 16 Characters x 2 Lines
- Green Backlight
- 5×7 Dot Matrix Character + Cursor
- HD44780 Equivalent LCD Controller/driver Built-In
- 4-bit or 8-bit MPU Interface
- Standard Type
- Works with almost any Microcontroller
-
SKU: n/a -
-
Arduino, Arduino Boards & Components, Development Kits
Cable for UNO
?Key Features :
- Fully compatible with the PC.
- Molded strain relief and PVC over-molding to ensure a lifetime of error-free data transmissions.
- Aluminum under mold shield helps meet FCC requirements on KMI/RFI interference.
- Foil and braid shield complies with fully rated cable specifications reducing EMI/FRI interference.
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
CH340G Usb To TtL (Serial) Converter For Arduino Nano Raspberry Pi
-6%Arduino, Arduino Boards & Components, Development KitsCH340G Usb To TtL (Serial) Converter For Arduino Nano Raspberry Pi
?Key Features :
- Dimensions: 53 x 18 x 7 (LxWxH) mm.
- Weight: 6gm.
- Built-in USB to TTL Transfer chip.
- Designed to be used for USB to TTL electronic projects.
- TTL interface output, easy to connect to your MCU.
- Dual 3.3V and 5V Power output, work with 3.3v and 5 V target device.
- The mini-module is designed specifically for STC download and ARDUINO PRO supports all series of STC
- Microcomputer with cold start reset button
- Supports WIN7/VISTA/MAC/LINUX(32 bit /64-bit system)
- USB to TTL conversion board used for STC microcontroller download DVD/ hard disk/router /GPS upgrade
- For STC Download: SCM must be a minimum system and external crystal oscillator
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
CP-2102 Usb To Serial Usb To Uart Ttl Serial Module
-2%Arduino, Arduino Boards & Components, Development KitsCP-2102 Usb To Serial Usb To Uart Ttl Serial Module
?Key Features :
- Stable and reliable chipset CP2102.
- USB specification 2.0 compliant with full-speed 12Mbps.
- Standard USB type A male and TTL 6pin connector.
- 6pins for 3.3V, RST, TXD, RXD, GND & 5V.
- Baud rates: 300 bps to 1.5 Mbps
- Byte receive buffer; 640 byte transmit buffer.
- Hardware or X-On/X-Off handshaking supported.
- Event character support Line break transmission.
- USB suspend states supported via SUSPEND pins.
- Temperature Range: -40 to +85.
- Size: 42mm X 15mm.
- Weight: 4g
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
DC Volt Meter 3 wire DC 4.5 to 30V DC Red LED digital voltmeter module panel meter
-2%Arduino, Arduino Boards & Components, Development KitsDC Volt Meter 3 wire DC 4.5 to 30V DC Red LED digital voltmeter module panel meter
?Key Features :
-
3 wire? 0-100V Red LED digital voltmeter module panel meter
- Sensing?Voltmeter: 0-100V.
- Power supply: DC4-30V
- Measuring range: 0-100V.
- Measurement accuracy: ?0.1%
- Refresh rate: about 200ms
- Display: 0.56 “digital tube
- Color: Red
- Operating current: Less than 8mA
- Operating temperature: -10?C to 65?C
- Input impedance:100K
- Overall dimension: 48*29*26mm
- Display LED color – Red
SKU: n/a -
-
Arduino, Arduino Boards & Components, Development Kits
DHT11 Temperature And Humidity Sensor
?Key Features :
- Low power consumption.
- DHT11 sensor adopts
- The module can detect the surrounding environment of the humidity and temperature
- High reliability and excellent long-term stability
- The output from the digital output
- Has a fixed bolt hole and easy installation
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
DHT22
?Key Features :
- High precision
- Capacitive type
- Full range temperature compensated
- Relative humidity and temperature measurement
- Calibrated digital signal
- Outstanding long-term stability
- Extra components not needed
- Long transmission distance
- Low power consumption
- 4 pins packaged and fully interchangeable
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
DRV8825 Stepper Motor Driver With Aluminum Heat Sink
-3%Arduino, Arduino Boards & Components, Development KitsDRV8825 Stepper Motor Driver With Aluminum Heat Sink
?Key Features :
-
-
- Model:?DRV8825
- Supply Voltage:?8.2 ? 42 VDC.
- Current Capacity :?2.2A max(24V).
- Continuous current per phase:?1.5 A.
- Minimum Logic voltage:?2.5V.
- Maximum Logic Voltage:?5V.
- Microstep resolutions:?full, 1/2, 1/4, 1/8, 1/16, and 1/32.
- Dimensions?: 15 x 20 mm.
- Weight:?4 gm.
- Microstep resolutions:?full, 1/2, 1/4, 1/8, 1/16, and 1/32.
- Simple step and direction control interface
- Six different step resolutions: full-step, half-step, 1/4-step, 1/8-step, 1/16-step, and 1/32-step
- Adjustable current control lets you set the maximum current output with a potentiometer. Hence lets you use voltages above your stepper motor?s rated voltage to achieve higher step rates
- Intelligent chopping control that automatically selects the correct current decay mode (fast decay or slow decay)
- 45?V maximum supply voltage
- Built-in regulator (no external logic voltage supply needed)
- Can interface directly with 3.3?V and 5?V systems
- Over-temperature thermal shutdown, over-current shutdown, and under-voltage lockout
- Short-to-ground and shorted-load protection
- 4-layer, 2?oz copper PCB for improved heat dissipation
- Exposed solderable ground pad below the driver IC on the bottom of the PCB
-
SKU: n/a -
-
Arduino, Arduino Boards & Components, Development Kits
DS1302 (Real Time Clock Ds1307 Ds 1307 Rtc I2c Module At24c32)
-3%Arduino, Arduino Boards & Components, Development KitsDS1302 (Real Time Clock Ds1307 Ds 1307 Rtc I2c Module At24c32)
?Key Features :
-
- Two-wire I2C interface
- Hour: Minutes: Seconds AM/PM
- Leap year compensation
- Accurate calendar up to the year 2100
- Consumes Less than 500nA in Battery-Backup
- 1Hz output pin
- 56 Bytes of Non-volatile memory available to the user
- 4KB of serial electrically erasable and programmable read-only memory (EEPROM)
- Embed DS18B20 temperature sensor interface with the pull-up resistor.
SKU: n/a -
-
Arduino, Arduino Boards & Components, Development Kits
DS3231 (Precision Rtc Real Time Clock Module With Cell)
-2%Arduino, Arduino Boards & Components, Development KitsDS3231 (Precision Rtc Real Time Clock Module With Cell)
?Key Features :
-
- DS3231 based RTC with 2032 Battery Holder.
- Highly Accurate RTC Completely Manages All Timekeeping Functions.
- Real-Time Clock Counts Seconds, Minutes, Hours, Date of the Month, Month, Day of the Week, and Year, with Leap-Year Compensation Valid Up to 2100.
- Digital Temp Sensor Output.
- Register for Aging Trim.
- Configurable I2C device Address for AT24C32 using SMD jumpers on PCB (A0, A1, A2).
- Two Time-of-Day Alarms.
- Programmable Square-Wave Output Signal.
- Battery-Backup Input for Continuous Timekeeping.
- Low Power Operation Extends Battery-Backup Run Time.
- 3.3V Operation.
SKU: n/a -
-
Arduino, Arduino Boards & Components, Development Kits
ESP-01S Esp8266 Wifi Module
?Key Features :
- 802.11 b/g/n
- Wi-Fi Direct (P2P), soft-AP
- Integrated TCP/IP protocol stack
- Integrated TR switch, balun, LNA, power amplifier and matching network
- Integrated PLLs, regulators, DCXO and power management units
- +19.5dBm output power in 802.11b mode
- Power down leakage current of <10uA
- 1MB Flash Memory
- Integrated low power 32-bit CPU could be used as an application processor
- SDIO 1.1 / 2.0, SPI, UART
- STBC, 1?1 MIMO, 2?1 MIMO
- A-MPDU & A-MSDU aggregation & 0.4ms guard interval
- Wake up and transmit packets in < 2ms
- Standby power consumption of < 1.0mW (DTIM3)
SKU: n/a -
Arduino, Arduino Boards & Components, Development Kits
ESP32+cp2102 Wroom Esp32 Wifi Based Microcontroller Development Board Nodemcu
-2%Arduino, Arduino Boards & Components, Development KitsESP32+cp2102 Wroom Esp32 Wifi Based Microcontroller Development Board Nodemcu
?Key Features :
-
- 100% brand new and high quality.
- ESP32 is already integrated antenna and RF balun,power amplifier,low-noise amplifiers,filters,and power management module.
- The entire solution takes up the least amount of printed circuit board area.
- This board is used with 2.4 GHz dual-mode Wi-Fi and Bluetooth chips by TSMC 40nm low power technology,power and RF properties best,which is safe,reliable,and scalable to a variety of applications.
- High performance-price ratio.
- Small volume,easily embeded to other products.
- Strong function with support LWIP protocol,Freertos.
- Supporting three modes:AP,STA,and AP+STA.
- Supporting Lua program,easily to develop.
SKU: n/a -
